Configuration

All configuration is via environment variables. Copy .env.example to .env and edit before starting.

MCP

MCP_ENABLED

Default: false

Enables the Streamable HTTP endpoint at POST/GET /mcp. It exposes read-only tools for readable content, HTML, screenshots and browser diagnostics. It does not add web search, ranking or result discovery. Keep the endpoint on a trusted private network; the endpoint does not provide authentication.

MCP_ENABLED=true

MCP_ALLOWED_ORIGINS

Default: (empty)

Comma-separated browser origins permitted to access /mcp. Server-to-server requests without an Origin header are accepted. When a browser sends Origin, it must exactly match an entry in this list.

MCP_ALLOWED_ORIGINS=https://chat.example.com,https://admin.example.com

Session Cache Driver

SESSION_CACHE_DRIVER

Default: redis

Selects the backend used for the Tier 2 session cache. Redis remains the default to preserve cross-instance session sharing and backward compatibility.

SESSION_CACHE_DRIVER=redis   # default - shared across instances, requires Redis
SESSION_CACHE_DRIVER=memory  # in-process Map, zero external dependencies

Use memory for single-instance deployments where running Redis is not justified. Sessions are scoped to the API process and lost on restart - they are not shared across instances. See Session Cache for details.

Unknown values stop startup with a configuration error instead of silently selecting another backend.

MEMORY_SESSION_CACHE_MAX_ENTRIES

Default: 1000

Maximum number of sessions retained by the memory driver. Once full, it evicts the least recently used session. Expired sessions are removed automatically on reads and writes.

Redis

REDIS_URL

Default: (empty - Redis driver disabled)

Standard Redis connection URL - the bundled Compose service uses Redis 8. Set a non-empty URL to enable the session cache. When running inside Docker Compose use the service name:

REDIS_URL=redis://redis:6379

With authentication:

REDIS_URL=redis://:yourpassword@redis:6379

With a specific database index:

REDIS_URL=redis://redis:6379/1

REDIS_CONNECT_TIMEOUT_MS

Default: 5000

Maximum duration of each Redis connection attempt. A failed attempt does not block the API or permanently disable Tier 2; TRAWL continues without the cache and reconnects in the background.

REDIS_RETRY_DELAY_MS

Default: 5000

Delay between background connection attempts. Set it to 0 when Redis is intentionally absent to disable retries. The supplied minimal Compose variant does this automatically.

REDIS_SESSION_TTL_SECONDS

Default: 3600 (1 hour)

How long either cache driver retains solved cookies and browser identity per hostname. After this TTL, the entry is unavailable for reuse; a protected request may need another browser solve.

The cache TTL does not extend a provider cookie's expiry. HTTP clearance reuse checks the actual cookie expiry and scope before sending it. Rejected clearance falls back to the browser tiers; a failed cached browser attempt invalidates the entry before a fresh solve. See Session Cache and Performance & Benchmarks.

REDIS_SESSION_TTL_SECONDS=3600   # default retention: one hour
REDIS_SESSION_TTL_SECONDS=1800   # shorter retention: 30 minutes

Scrape Timeout

SCRAPE_MAX_TIMEOUT_MS

Default: 60000 (60 seconds)

Default total scrape deadline in milliseconds for /scrape, FlareSolverr /v1, MCP tools and MITM scraper fallbacks. A request's explicit maxTimeout takes precedence, whether shorter or longer. This setting supplies a default rather than a deployment-wide ceiling.

SCRAPE_MAX_TIMEOUT_MS=120000

Accepts integers from 1 to 2147483647, the largest supported timer delay. Unset or blank values use 60 seconds; invalid values stop startup. The deadline includes HTTP requests, browser acquisition, navigation, solving and capture. Cleanup remains separately bounded. Direct proxy Tier 0 forwarding retains its existing network timeouts.

Scrape Tier Floor

SCRAPE_MIN_TIER

Default: 1

Sets the lowest tier that /scrape, FlareSolverr /v1, MCP tools, and MITM scraper fallbacks may use. Tier 1 preserves the normal plain HTTP fast path, 2 starts with a cached browser session, 3 starts with a fresh browser solve, and 4 goes directly to a residential or explicitly supplied proxy. Tier 2 is skipped naturally when no cached session exists.

SCRAPE_MIN_TIER=1   # normal adaptive ladder
SCRAPE_MIN_TIER=2   # never make the plain HTTP request
SCRAPE_MIN_TIER=3   # never reuse a cached browser session
SCRAPE_MIN_TIER=4   # require residential or per-request proxy routing

Use a floor above 1 when an early request itself affects the target's fingerprint or when every request must reach a particular proxy-backed tier. Higher floors increase latency and browser-pool load. An invalid value stops TRAWL at startup, and a request whose maxTier is below the configured floor fails before any outbound request. The native API's skipHttp: true can raise the effective floor to Tier 2 but cannot lower this deployment-wide setting.

For the MITM forward proxy, this setting applies only after the request enters the scraper ladder. Set MITM_ALWAYS_SCRAPE=true as well when the proxy's direct Tier 0 probe must also be disabled.

Tier 1 HTTP Transport

TIER1_TRANSPORT

Default: bun

Choose bun for Bun's native fetch or wreq for Firefox TLS/HTTP2 impersonation through the bundled node-wreq addon. Both run under Bun; Node.js is not required by the scraper service. Invalid values stop startup.

TIER1_TRANSPORT=wreq

The native binding initializes at startup only when selected. It selects the newest numbered Firefox profile supported by the pinned package and uses its matching Linux User-Agent for fresh HTTP requests. This profile is not necessarily the same browser version as Camoufox. Eligible clearance replays retain their saved browser User-Agent and cookies; rejected clearance falls back to the browser.

This option can help targets that reject the default HTTP fingerprint. It does not replace browser CAPTCHA solving or guarantee higher success. The addon adds native memory and worker threads. Select it for workloads that benefit from it.

Proxy routing, TLS verification, request deadlines and encoded response bytes are preserved. Native cancellation stops the caller's read immediately, but native resources can remain until the original HTTP deadline. A rejected clearance replay keeps its shorter HTTP deadline before browser fallback.

The MITM listener's direct Tier 0 forwarding is unchanged. Set MITM_ALWAYS_SCRAPE=true if proxy requests must enter the scraper ladder.

User Prefs

USER_PREFS

Default: (unset)

A JSON object of Firefox prefs applied to every launched browser, merged after TRAWL's built-in launch prefs. Values must be strings, booleans or signed 32-bit integers; arrays, objects, null and fractional numbers are rejected at startup. Prefs apply at browser launch, so restart TRAWL after changing them.

For a deployment that already routes .onion traffic through Tor and supplies DNS:

USER_PREFS={"network.dns.blockDotOnion":false}

network.proxy.failover_direct=false and network.proxy.socks_remote_dns=true remain enforced even if supplied in USER_PREFS. Other preferences can override built-in values, including process counts, so configure them with your resource limits in mind.

Browser Pool

METRICS_DASHBOARD_ENABLED and METRICS_DASHBOARD_TOKEN

Default: (unset)

For a port bound to 127.0.0.1, set METRICS_DASHBOARD_ENABLED=true to open the local dashboard without a token. If the port can be reached by others, set a random token of at least 32 characters. The token is sent as a Bearer header and held only in the browser tab's memory; it takes precedence over the tokenless setting. See the metrics guide.

METRICS_DASHBOARD_ENABLED=true
# Or use a token for authenticated access:
# METRICS_DASHBOARD_TOKEN=<random-secret-at-least-32-characters>
METRICS_DB_PATH=/data/metrics/trawl.sqlite

LOG_LEVEL

Default: info

Controls correlated operational logging. info records every scrape start, tier outcome, and final success or failure with a correlation ID. In these correlated entries, URLs omit credentials, query strings, and fragments, and request bodies, headers, cookies, and proxy credentials are not logged. Use warn, error, or silent to reduce these entries; debug also admits future verbose operational events. Solver progress writes separate diagnostic lines that can include CAPTCHA answers, token previews, transcription output, frame URLs, and audio URLs. Treat logs as sensitive and configure access control and Docker log rotation accordingly.

LOG_LEVEL=info

BROWSER_POOL_SIZE

Default: 1

Number of Camoufox Firefox instances to keep warm. Each instance uses ~350-500 MB RAM under load. Start conservative and raise if you need higher concurrency.

BROWSER_POOL_SIZE=1   # default - recommended for Prowlarr and ordinary scraping
BROWSER_POOL_SIZE=3   # concurrent browser solves; allow at least 2 GB RAM
BROWSER_POOL_SIZE=8   # high-throughput (6+ GB host RAM)

Note: Pool size controls concurrency, not solver capability. The API container sets shm_size: 1gb by default. Shared memory does not replace the container memory limit.

BROWSER_ACQUIRE_TIMEOUT_MS

Default: 15000 (15 seconds)

Maximum queue wait for a free browser before rejecting with PoolExhaustedError. Queue time also consumes the request's remaining maxTimeout: the shorter deadline wins. Waiting requests wake when capacity becomes available, without periodic queue polling. The default pool intentionally favors low memory use; raise the pool when sustained concurrent browser solves are expected.

Lower it for fail-fast client feedback (Prowlarr will see 429s sooner and retry on its own). Raise it for very heavy upstream targets or when you've bumped BROWSER_POOL_SIZE higher.

BROWSER_ACQUIRE_TIMEOUT_MS=5000    # fail fast - 429s after 5s
BROWSER_ACQUIRE_TIMEOUT_MS=15000   # default - bounded queue before HTTP 429
BROWSER_ACQUIRE_TIMEOUT_MS=30000   # tolerate longer queueing on slow targets

When the timeout fires, both /v1 and /scrape return HTTP 429 with the FlareSolverr v2 error envelope (not a 500).

BROWSER_RECYCLE_AFTER_CONTEXTS

Default: 8

How many Tier 3 or Tier 4 temporary contexts a pooled browser can create before TRAWL replaces the browser process. Every context counts, regardless of outcome. With at least 512 MiB of container memory headroom, TRAWL warms one replacement while the existing browser remains available. In containers limited to 1 GiB or less, or with less headroom, it closes the old browser first; queued requests may wait for the new browser to start.

The API reads Linux cgroup v1/v2 memory usage, subtracting reclaimable inactive file cache for recycling decisions. After a browser-backed request finishes, working-set usage above 85% of the container limit also requests recycling. Outside supported cgroups, only context-count recycling applies. This reduces sustained memory growth and replacement peaks; it cannot prevent a single memory-heavy page or CAPTCHA from exhausting the container.

BROWSER_RECYCLE_AFTER_CONTEXTS=8   # default - replace after 8 Tier 3/4 contexts
BROWSER_RECYCLE_AFTER_CONTEXTS=0   # disable count-based recycling; memory-pressure recovery remains

BROWSER_IDLE_TIMEOUT_MS

Default: 0 (disabled).

Retire an unused browser after this many milliseconds. The next browser-backed request launches it again; ordinary HTTP scraping stays available. Session cookies stored in the configured cache survive idle retirement. The first browser request after retirement pays a cold start, and Firefox's in-memory cache is lost. Active requests, cleanup and queued acquires prevent retirement. The health endpoint counts intentionally sleeping capacity separately from live browsers.

BROWSER_IDLE_TIMEOUT_MS=300000 # optional: retire after five minutes idle

BROWSER_BLOCK_ADS

Default: true

Load Camoufox's bundled uBlock Origin extension. Set false to omit it and reduce extension memory and CPU overhead. Both headless and optional headful pools use this setting. Ads, trackers and other resources normally blocked by uBlock can then load; resource use may increase on ad-heavy pages. Scripts, images, proxy routing and TLS verification otherwise retain their existing behavior.

For a small single-browser container, start with:

BROWSER_POOL_SIZE=1
BROWSER_MAX_CONTENT_PROCESSES=2
BROWSER_HARDWARE_CONCURRENCY=4
BROWSER_BLOCK_ADS=false

This is a resource tuning option, not a guarantee that every browser workload fits in 1 GiB. Use a larger limit for heavy pages, difficult CAPTCHAs or the additional headful pool.

BROWSER_HARDWARE_CONCURRENCY

Optional browser-reported logical CPU count, from 1 to 64. Unset preserves Camoufox's generated fingerprint. This changes the native browser configuration, rather than injecting JavaScript into target pages.

PoW implementations such as Anubis size their worker pool from this value. For a small container, try BROWSER_HARDWARE_CONCURRENCY=4 with BROWSER_POOL_SIZE=1. Fewer workers can reduce CPU and RAM usage, but may take longer to solve difficult challenges. This is not a hard CPU or memory limit; configure those in Docker.

BROWSER_MAX_CONTENT_PROCESSES

Default: 2

Caps Firefox content processes per pooled browser via the dom.ipc.processCount Firefox pref. Firefox's default of 8 lets thread count climb when Tier 3 / Tier 4 churn disposable contexts (see #13). The cap bounds the leak at the source without paying the recycle cost. Raise if specific targets fail with empty content (rare).

BROWSER_MAX_CONTENT_PROCESSES=2   # default content-process preference
BROWSER_MAX_CONTENT_PROCESSES=4   # raise if CF/Imperva challenges stall

BROWSER_HEADFUL_POOL_SIZE

Default: 0 (disabled)

Browsers in the headful sub-pool. This pool runs behind an Xvfb virtual display and serves DataDome Device Check escalations that require a browser running behind a display.

Set it to 1 to scrape DataDome targets. It is off by default because the sub-pool is additional to BROWSER_POOL_SIZE: one headful browser plus its X display measures about 380 MB (a headful browser is roughly twice a headless one, and Xvfb adds ~65 MB), so leaving it on would move the memory ceiling of deployments that never meet DataDome. Account for it in mem_limit before enabling.

When enabled, the sub-pool is warmed during API startup. A launch failure therefore fails startup instead of delaying an individual scrape. Readiness at /health reports the main pool only; the sub-pool appears under headful at /stats, and reads null while disabled.

With the sub-pool disabled, a DataDome escalation fails immediately with a configuration error.

The container images ship the xvfb binary.

BROWSER_HEADFUL_POOL_SIZE=0   # default - no headful browser
BROWSER_HEADFUL_POOL_SIZE=1   # required for DataDome targets, ~380 MB on first use

Browser recovery timeouts

Variable	Default	Purpose
BROWSER_STALL_TIMEOUT_MS	180000	Grace period after a request's own timeout before its browser checkout is reclaimed
BROWSER_CLOSE_TIMEOUT_MS	10000	Maximum wait for a wedged browser or context to close
BROWSER_LAUNCH_TIMEOUT_MS	90000	Maximum wait for Camoufox to launch

These bounds keep an unresponsive Firefox process from permanently consuming a pool slot. The defaults are suitable for most installations.

BROWSER_SHUTDOWN_DRAIN_MS

Default: 0 (close at once)

How long shutdown on SIGTERM or SIGINT lets accepted HTTP requests finish before closing sessions and browser pools. The API stops accepting new connections immediately. Existing requests, including HTTP-only scrapes, queued browser requests and named sessions, can finish within this window. At the deadline, remaining HTTP connections are closed and cleanup begins without another drain interval. Long-lived streams can use the entire window. The MITM proxy keeps its separate, bounded shutdown behavior.

/stats includes the pool's draining flag once pool shutdown begins; the API listener is already stopped at that point. The forced-exit deadline is the configured drain plus 30 seconds. Invalid values fall back to 0; the maximum accepted value is 2147453647 ms, leaving room for the forced-exit timer.

Set it no higher than your supervisor's grace period minus the time to close the browsers, or the supervisor kills the process mid-drain. In Kubernetes that is terminationGracePeriodSeconds; with Docker Compose it is stop_grace_period, which defaults to 10 seconds. A request that has to solve a challenge can take minutes, so a useful drain is usually minutes too.

BROWSER_SHUTDOWN_DRAIN_MS=0        # default - close in-flight requests at once
BROWSER_SHUTDOWN_DRAIN_MS=240000   # wait up to 4 minutes; pair with a 300s grace period

The supplied Compose files pass this variable from .env. Set the matching stop_grace_period in a Compose override, for example:

services:
  trawl:
    stop_grace_period: 300s
    environment:
      BROWSER_SHUTDOWN_DRAIN_MS: "240000"

Screenshots

Only read when a request sets screenshot: true - see Native API.

Variable	Default	Purpose
SCREENSHOT_SETTLE_MS	3000	Maximum wait for the network to go idle before capturing
SCREENSHOT_TIMEOUT_MS	10000	Maximum wait for the capture itself
SCREENSHOT_JPEG_QUALITY	60	JPEG quality, 1-100
SCREENSHOT_MAX_BYTES	4000000	Images larger than this are dropped rather than returned

A screenshot is never worth failing a scrape: exceeding any of these bounds leaves screenshot unset and logs the reason, and the scrape result is otherwise unchanged. Tier 1 is a plain HTTP fetch and never captures a screenshot. Set skipHttp: true if you need to force a browser-tier attempt.

Console and Network Diagnostics

Only read when a request sets consoleLogs or networkLogs - see Native API. Without those flags no listener is attached and nothing is buffered.

Variable	Default	Purpose
DIAGNOSTICS_MAX_CONSOLE_ENTRIES	500	Console messages kept per page
DIAGNOSTICS_MAX_NETWORK_ENTRIES	1000	Requests kept per page
DIAGNOSTICS_MAX_STRING_CHARS	2000	Longest single console message or request URL kept
DIAGNOSTICS_MAX_TOTAL_CHARS	1000000	Total characters kept across both arrays
DIAGNOSTICS_SIZE_TIMEOUT_MS	2000	Maximum wait for the browser's per-request byte counts

Anything past a cap is dropped whole rather than truncated, and the number of dropped entries is logged once per scrape. A capture failure leaves the field unset and never fails the scrape.

Console messages and request URLs may contain credentials, tokens, personal data, or other sensitive values. Treat diagnostic fields as sensitive output and avoid storing or forwarding them unless necessary.

Redirect Capture

Only read when a request sets redirectChain. The tracker records only top-level document URLs; subresource redirects are excluded.

Variable	Default	Purpose
REDIRECT_MAX_ENTRIES	50	URLs kept in the redirect chain
REDIRECT_MAX_URL_CHARS	2000	Longest individual redirect URL kept
REDIRECT_MAX_TOTAL_CHARS	1000000	Total characters kept across the redirect chain

Response-Body Capture

Only read when a request sets captureResponses - see Native API. Without patterns no listener is attached and no body is read.

Variable	Default	Purpose
CAPTURE_MAX_PATTERNS	10	URL patterns honoured per request
CAPTURE_MAX_RESPONSES	5	Bodies kept per page, in arrival order
CAPTURE_MAX_BODY_BYTES	5242880	Bytes kept per body; past it the body is trimmed and flagged truncated
CAPTURE_MAX_TOTAL_BYTES	10485760	Bytes kept across all bodies of one page
CAPTURE_MAX_READ_BYTES	10485760	Largest body this process will read at all; a larger one is reported with an error instead of a trimmed prefix
CAPTURE_MAX_METADATA_CHARS	2000	Longest captured URL, header name, header value, or error kept
CAPTURE_BODY_TIMEOUT_MS	5000	Maximum wait for in-flight body reads when the capture is drained
CAPTURE_SETTLE_MS	15000	Default settle window when a request does not set settleTimeout
CAPTURE_MAX_SETTLE_MS	60000	Ceiling a request may ask for; the request's own time budget also caps it
CAPTURE_IDLE_FLOOR_MS	5000	Network idle is ignored for this long, so a data fetch on a delayed timer is not mistaken for a quiet page

A response that matched but whose body could not be read is still returned, with body null and error set, so "nothing matched" stays distinguishable from "matched, retrieval failed".

A body read cannot be cut short once it has started - the browser API returns whole bodies only - so the budgets above bound what is read, not just what is kept. Only identity-encoded bodies with a valid Content-Length are read. Compressed or unknown-size bodies are returned with body: null and an error. Declared sizes are reserved cumulatively before reads start, so concurrent responses cannot exceed the total read budget.

Blocked-Outcome Evidence

Only retained when a request sets blockedEvidence: true - see Native API. Without it the failure path captures no additional image or response data. Only the last wall is kept per request, and its markup, screenshot size and screenshot time are all bounded.

Variable	Default	Purpose
BLOCKED_EVIDENCE_MAX_HTML_CHARS	512000	Characters of the wall kept; past it html is the head of the page and htmlTruncated is set

The wall is truncated rather than dropped: unlike a stylesheet or an image, the head of a challenge page still carries the title, vendor markers and incident id a caller classifies on. Capturing it never fails the scrape, and screenshots cannot extend the request budget. Challenge markup and screenshots can contain tokens, credentials or personal data; avoid logging, persisting or publicly exposing them unless that is explicitly intended.

Favicons

Only read when a request sets favicons: true - see Native API. Without it no icon is resolved and no request is made.

Variable	Default	Purpose
FAVICON_MAX_ENTRIES	8	Icons fetched per page, apex first then declared in document order
FAVICON_MAX_BYTES	524288	Largest single icon kept. Declared oversize bodies are refused; unknown-size bodies are streamed and cancelled when they cross the cap
FAVICON_MAX_METADATA_CHARS	8192	Maximum characters kept for an icon URL, content type, or error message
FAVICON_FETCH_TIMEOUT_MS	5000	Maximum wait for one icon
FAVICON_TIMEOUT_MS	20000	Ceiling on the whole collection; the request's own remaining maxTimeout also caps it, and collection is skipped once that budget is spent

An icon that could not be read is returned with error set rather than dropped, and a collection failure leaves favicons empty and never fails the scrape. Tier 1 has no page context and therefore never produces icons; use skipHttp: true when the response must contain the requested favicon collection.

MHTML Archives

Only read when a request sets mhtml: true - see Native API. Without it no subresource body is read. The archive keeps many small parts rather than a few large bodies, so it carries budgets of its own rather than sharing the response-body ones.

Variable	Default	Purpose
MHTML_MAX_PARTS	200	Subresources archived per page
MHTML_MAX_PART_BYTES	2097152	Bytes per subresource; a larger one is omitted whole
MHTML_MAX_TOTAL_CHARS	8388608	Maximum characters in the complete serialized archive, including the rendered root and MIME overhead
MHTML_MAX_INFLIGHT_READS	32	Subresource bodies read at the same time; a burst past this is omitted rather than held
MHTML_MAX_OMISSION_RECORDS	100	Omissions listed by URL in the archive; the rest are only counted

Bodies are read as they arrive, so a page whose subresources all complete at once is bounded by MHTML_MAX_INFLIGHT_READS and by the archive budget reserved from each valid Content-Length. Because the browser API returns only complete bodies, compressed and unknown-size responses are omitted before reading rather than trusted after allocation. When captureResponses selects the same resource, both outputs share one browser body read.

A subresource is omitted rather than trimmed - a truncated stylesheet or image is corrupt, not partial. Every omission is counted in the archive's X-Trawl-Omitted-Resources header; up to MHTML_MAX_OMISSION_RECORDS are listed in its final part. Non-HTML responses, a root that cannot fit the total cap, or an assembly failure leave mhtml unset and never fail the scrape. Archives may contain credentials, personal data and executable target scripts, so treat them as sensitive untrusted output.

Optional external CAPTCHA solver

Built-in solvers remain the default. Set CAPTCHA_SOLVER=2captcha and TWOCAPTCHA_API_KEY to try a paid fallback after local solving fails. A key by itself never enables the service. No additional model or solver SDK is installed.

Variable	Default	Description
CAPTCHA_SOLVER	none	none or 2captcha
TWOCAPTCHA_API_KEY	unset	Required when selecting 2Captcha; keep it secret
CAPTCHA_SOLVER_MAX_TASKS	1	Maximum paid task creation attempts per scrape, shared across tiers and proxy retries; range 1-3
CAPTCHA_SOLVER_LOCAL_TIMEOUT_MS	10000	Budget offered to a supported built-in solver before fallback; range 1000-30000 ms
CAPTCHA_SOLVER_TIMEOUT_MS	120000	External operation limit, also capped by the remaining scrape budget; range 1000-180000 ms
CAPTCHA_SOLVER_PROFILES	unset	JSON array of hostname-specific task and delivery profiles; up to 64 profiles, 256 KB total

CAPTCHA_SOLVER=2captcha
TWOCAPTCHA_API_KEY=your-key

Automatic widget fallback

The default adapter handles one declarative reCAPTCHA v2, v2 Enterprise or standalone Turnstile widget per provider on a page, with data-sitekey and an optional named data-callback. It installs the response in the current page and invokes the callback in the page's JavaScript realm. It does not submit forms itself. Turnstile custom response fields, callback-only widgets and reCAPTCHA compatibility mode are supported. reCAPTCHA uses the browser user agent and the widget's Google or recaptcha.net API domain. Enterprise data-s is sent inside enterprisePayload.

A restrictive script CSP or missing named callback prevents task creation. Anonymous callbacks, explicitly rendered standalone widgets, multiple widgets and reCAPTCHA v3 require a site-specific profile. Existing local solvers, including hCaptcha, remain available. A token delivered to a field is reported as delivered, not as proof of target-server acceptance.

Cloudflare Challenge Pages

When external solving is enabled, TRAWL installs a page-scoped observer before navigation in fresh browser tiers 3 and 4, including named browser sessions. For Turnstile-based Challenge Pages with #challenge-form, it captures the render call's sitekey, action, cData, chlPageData and callback together with the browser's actual user agent. These values are document-specific; no static site profile is required. The original render still runs so local solving gets its first attempt. Delayed SDK initialization is supported within the local wait.

After the local attempt, a complete pending render can create a TurnstileTask using the browser's explicit proxy, or a TurnstileTaskProxyless without one. The returned token is delivered to the captured callback in the same document. Reloading, rendering a replacement widget, reset, expiration or local completion invalidates the captured answer. A provider user agent that differs from the browser is rejected rather than partially changing the browser identity.

TRAWL then checks for readable content and absence of the challenge before reporting cloudflare-challenge:2captcha in captchasSolved. A token, callback return or cf_clearance cookie alone is insufficient. Hard error pages such as 1020/1015 do not create paid tasks. Missing render parameters retain local handling and tier fallback; not every Cloudflare challenge exposes this flow. The same allowance, cooldowns and request deadline apply as for other external tasks. Keep enough time for both the provider's five-second polling interval and target verification. No additional browser or background polling loop is used.

Provider task catalogue

TRAWL validates the API v2 task shapes documented by 2Captcha. The catalogue covers reCAPTCHA v2/Enterprise/v3, Turnstile, Arkose/FunCaptcha, GeeTest, Capy, KeyCaptcha, Lemin, AWS WAF, CyberSiara, MTCaptcha, DataDome, Friendly Captcha, CutCaptcha, ATB, Tencent, Prosopo, CaptchaFox, VK, ALTCHA, Yidun, Binance, Hunt, TSPD, Basilisk, Imperva, Alibaba and Yandex, plus image/text/audio, rotation, coordinates, grids, drawing, bounding boxes, drag-and-drop, Temu, SmartCaptcha and Pazl tasks.

Recognizable SDK and widget markers produce diagnostic candidates. A marker alone never starts a paid task. Apart from the automatic widgets above, these tasks need a profile providing the required dynamic parameters and a way to apply and verify the response. Generic images or audio are not automatically classified as CAPTCHA. Detection cannot cover every customized website or SDK variant. hCaptcha is not included in the current API v2 catalogue used here; no undocumented external task type is sent.

The catalogue accepts the alternative names and field spellings present in the provider's examples, including Imperva/Incapsula and Alibaba. Those documentation inconsistencies have not been resolved against a live paid account. Structural validation is not a guarantee that the provider will accept a task.

Site-specific profiles

Profiles are server configuration, not request parameters. Each profile binds an exact lowercase hostname, a unique widget root, a documented taskType, task inputs and an explicit delivery method. The selector must identify one widget; missing or ambiguous targets prevent payment. No wildcard hostnames are allowed.

For example, save this array as the JSON value of CAPTCHA_SOLVER_PROFILES:

[
  {
    "hostname": "example.com",
    "selector": "#captcha",
    "taskType": "GeeTestTaskProxyless",
    "inputs": {
      "gt": { "selector": "#captcha", "attribute": "data-gt" },
      "challenge": { "source": "global", "path": ["captchaConfig", "challenge"] }
    },
    "delivery": {
      "fields": [
        { "selector": "#geetest-challenge", "path": ["challenge"] },
        { "selector": "#geetest-validate", "path": ["validate"] },
        { "selector": "#geetest-seccode", "path": ["seccode"] }
      ],
      "callback": "captchaAccepted",
      "verifySelector": "#protected-content"
    }
  }
]

Use selectors and callback names belonging to your target integration. The example is a schema illustration, not a universal GeeTest configuration. Configured hostnames force otherwise successful HTTP HTML responses through a browser so the widget can be inspected; enabling a profile therefore has a browser cost even on pages without its widget. maxTier still limits execution.

Input	Meaning
{ "value": ... }	Explicit literal task parameter
{ "selector": "...", "attribute": "..." }	Unique element's attribute; without an attribute, its input value or text
{ "selector": "...", "json": true }	Parse the selected value as JSON
{ "source": "global", "path": ["config", "key"] }	Read a named page global; requires page CSP to allow the bridge
{ "source": "url" } / { "source": "userAgent" }	Current browser URL / user agent
{ "source": "screenshot", "selector": "..." }	PNG crop of one element, at most 100 KB before Base64 encoding
{ "source": "cookies" } / { "source": "html" }	Current-site cookies / page HTML; requires allowSessionData: true

Where the task supports them, websiteURL and userAgent default to the current browser values. A configured website URL must equal the current page URL. htmlPageBase64 from the HTML source is Base64 encoded. Inputs are checked against the task's supported fields, types and required combinations. Incomplete tasks are skipped. Profile task JSON is limited to 3 MB; provider responses to 512 KB.

Delivery paths are arrays indexing the provider's solution object; an empty path selects the whole value. Use only the paths documented for that task:

• fields: unique input/textarea selectors and response paths. Values must be nonempty strings; TRAWL emits input/change events.
• callback and optional callbackPath: call a named function with one selected response value, including a structured object. Without a path, pass the whole solution. No arbitrary JavaScript is evaluated from configuration.
• cookies: an explicit name, response path and format (value or set-cookie). Cookies are restricted to the current URL. Provider-supplied Domain/Path attributes are discarded; unrelated domains cannot be updated.
• clicks: a unique target, response path and mode. grid uses one-based cell numbers with configured rows and columns (1-20 each). coordinates uses {x,y} values within the PNG identified by imageInput, scaled to the target's browser bounds. At most 32 clicks are applied. Drawing, dragging and rotation responses need a target-specific callback or field adapter.
• submitSelector: optional explicit submission after fields/clicks, restricted to the widget or its surrounding form. Use a callback or submit selector, not both. Submission is never inferred.
• reload: optionally reload after installing cookies or values.
• verifySelector: required unique visible success element, initially absent or hidden. TRAWL waits for this state within the remaining request budget. Choose an element that appears only after server acceptance; a cosmetic UI change is not independent verification.

The complete task is read again before delivery. Changed challenge parameters, page navigation while waiting, missing targets and incompatible returned browser identities reject the response. Dynamic image grids that replace themselves mid-task need a new attempt; the request-wide task allowance still applies.

Native results include captchaDiagnostics with provider kind and status such as profile-required, incomplete-profile, ready, verified, delivery-failed, identity-mismatch, provider-failed or cancelled. The diagnostics contain no parameters or credentials. Verified profiles appear in captchasSolved as <kind>:2captcha. The Prowlarr response shape remains unchanged.

For supported widgets, local solving receives at most half the remaining widget budget, capped by the local timeout setting. Disabling the provider preserves the original local budget. The external phase polls at five-second intervals and does not extend maxTimeout. No paid task is created when five seconds or less remain; other short scrape budgets may still expire before workers finish. Increase maxTimeout within the API's supported limits when needed. Temporary polling failures receive at most two consecutive retries for the same task, five seconds apart. Reloading or navigating the page while waiting aborts delivery, and changed widget parameters reject the returned token.

An explicit HTTP, SOCKS4 or SOCKS5 browser proxy is passed to the provider instead of silently switching to a proxyless task. HTTPS proxy URLs are currently skipped by this adapter. The provider must be able to reach the supplied proxy; local Tor or Gluetun endpoints may not be reachable from its workers. Implicit VPN or Firefox proxy preferences are not converted into provider proxy settings. Profiles must select the proxy or proxyless task variant matching the actual browser route; proxy-required tasks are skipped without an explicit supported proxy. Tasks with no proxy variant are skipped when a browser proxy is configured.

Enabling this feature sends the full target URL, sitekey, supported widget parameters, the reCAPTCHA or Cloudflare browser user agent and explicit proxy credentials to 2Captcha. Browser session cookies and page content are sent only by explicitly configured profile inputs with allowSessionData: true. Image/audio tasks send their configured media. Provider API traffic uses the server's network route, rather than the browser's per-context proxy. TRAWL does not log the API key, provider error descriptions or returned token in this adapter.

Each creation attempt consumes the allowance even if the connection fails: the provider may have created a billable task before the response was lost. TRAWL never retries task creation automatically. Stopping a request cancels local polling but cannot cancel or refund a task already accepted by the provider. This is a task-count limit, not a deployment-wide spending cap. No-slot and HTTP 429 responses pause new external tasks for five seconds. Invalid keys, zero balance and account/IP restrictions pause them for sixty seconds. These cooldowns are shared by scrapes using the same provider configuration in one process; local solving continues with its original budget during a cooldown.

Browser fixtures and the official task examples are tested without submitting paid tasks. Real worker acceptance, latency, billing and success rates remain unverified.

See the provider's reCAPTCHA v2, Turnstile and polling API documentation.

CAPTCHA audio and media tools

TRAWL uses ffmpeg while solving supported CAPTCHA challenges. reCAPTCHA audio is converted before speech recognition, and the GeeTest solver uses it during image processing.

Variable	Default	Purpose
STT_URL	-	Optional Whisper/OpenAI-compatible transcription endpoint
STT_API_KEY	-	Optional bearer token sent only to STT_URL
FFMPEG_PATH	ffmpeg	Executable name or absolute path used by the CAPTCHA solvers

Without STT_URL, reCAPTCHA audio uses Google's public speech-recognition endpoint. When STT_URL is configured, TRAWL sends a multipart whisper-1 transcription request and adds Authorization: Bearer <STT_API_KEY> when a key is present.

The API container already includes ffmpeg. Bare-metal installations must make ffmpeg available on PATH or set FFMPEG_PATH. These values are read only by CAPTCHA solving; ordinary scrapes do not contact the configured STT service. Treat STT_API_KEY as a secret and avoid committing it to .env.

Proxies

PROXY_URL

These environment-level proxies are escalation pools: direct Tier 1 and cached Tier 2 may complete before they are used. In contrast, the API request-level proxy field is a routing guarantee; target traffic for that request never falls back to a direct connection.

Default: (empty - no proxy)

Datacenter proxy pool used for Tier 3 (fresh challenge solve). TRAWL passes these endpoints to the browser and supports HTTP and SOCKS5 forms:

PROXY_URL=http://dc-proxy.example.com:8080
PROXY_URL=http://user:pass@dc-proxy.example.com:8080
PROXY_URL=socks5://dc-proxy.example.com:1080

SOCKS5 destination hostnames are resolved by the proxy rather than the TRAWL host. This avoids local DNS leaks and allows the proxy resolver to reach domains blocked or poisoned by the local network. Use the standard socks5:// form shown above; socks5h:// is a curl-specific spelling and is not accepted by the browser API.

HTTP credentials can be embedded in the URL. For multiple endpoints, use a comma-separated list:

PROXY_URL=http://user:pass@dc1.example.com:8080,http://user:pass@dc2.example.com:8080

Leave empty to run Tier 3 without a proxy (your server's real IP is used).

RESIDENTIAL_PROXY_URL

Default: (empty - Tier 4 disabled)

Residential proxy pool used for Tier 4 (when the datacenter IP is flagged). Same format as PROXY_URL - single URL or comma-separated list. Tier 4 is completely skipped if this variable is not set and no per-request proxy override is supplied.

RESIDENTIAL_PROXY_URL=http://user:pass@residential.example.com:8080
RESIDENTIAL_PROXY_URL=socks5://residential.example.com:1080

Provider labels such as "rotating", "sticky", "country", or "session" do not change the TRAWL format. Use the hostname, port, and credentials supplied by the provider.

PROXY_LIST_FILE / RESIDENTIAL_PROXY_LIST_FILE

Default: (empty)

Alternative to cramming a large proxy list into PROXY_URL/RESIDENTIAL_PROXY_URL - path to a file with one proxy URL per line (# comments allowed). Merged with the corresponding *_URL env var if both are set.

PROXY_LIST_FILE=/etc/trawl/datacenter-proxies.txt
RESIDENTIAL_PROXY_LIST_FILE=/etc/trawl/residential-proxies.txt

Example file:

# /etc/trawl/residential-proxies.txt
http://user:pass@residential-1.example.com:8080
http://user:pass@residential-2.example.com:8080
socks5://residential-3.example.com:1080

When using Docker, the path is inside the TRAWL container. Mount the file and pass the same in-container path:

services:
  trawl:
    environment:
      RESIDENTIAL_PROXY_LIST_FILE: /etc/trawl/residential-proxies.txt
    volumes:
      - ./residential-proxies.txt:/etc/trawl/residential-proxies.txt:ro

For a single endpoint or a short pool, a local .env beside docker-compose.yml is enough:

RESIDENTIAL_PROXY_URL=http://user:pass@residential.example.com:8080

The supplied Compose files pass the proxy pool sources and selection policy into the container.

Rotation and failure handling

SCRAPE_PROXY_SELECTION controls how both datacenter and residential pools choose an endpoint:

Value	Behavior
failover (default)	Keeps a proxy sticky per domain. New domains spread round-robin, and a domain moves only after its proxy is blocked. This best preserves IP continuity for challenge-heavy targets.
roundrobin	Chooses the next healthy endpoint whenever a request enters Tier 3 or Tier 4, including repeat requests to the same hostname.
random	Randomly chooses a healthy endpoint whenever a request enters Tier 3 or Tier 4.

Selection happens only when a request actually reaches a proxy-backed tier. A request completed by Tier 1 or cached Tier 2 does not advance the pool; use SCRAPE_MIN_TIER=3 when every scrape must enter proxy selection. The setting rotates configured endpoints, not the exit IP behind a single provider-managed rotating gateway. Rotation state is local to each TRAWL process and is not coordinated across replicas.

The selected proxy stays fixed for the whole tier attempt, including a headful retry. If an attempt comes back "blocked", the endpoint enters a 5-minute cooldown and that request retries once with the next available proxy before falling through (Tier 3 → Tier 4, or Tier 4 failing outright). The two-attempt limit prevents a large list from exhausting the request's maxTimeout.

Per-request override

Both POST /scrape and POST /v1 accept an optional proxy field in the request body - when present, it's used directly for that request's Tier 3/4 attempts instead of the configured pool (and isn't retried against other pool proxies on failure, since it's caller-supplied):

{ "url": "https://example.com", "proxy": "http://user:pass@my-proxy.example.com:8080" }

Note: proxy on /v1 is a TRAWL-specific extension - it is not part of the real FlareSolverr v2 contract, so other FlareSolverr-compatible clients simply won't send it.

Test an endpoint

Test an HTTP proxy independently before starting TRAWL:

curl --proxy http://user:pass@proxy.example.com:8080 https://api.ipify.org

For SOCKS5, use curl's socks5h:// spelling to test the same proxy-side DNS behavior TRAWL enables in Firefox:

curl --proxy socks5h://proxy.example.com:1080 https://api.ipify.org

Use the provider's exact endpoint and authentication details. A working curl test confirms connectivity, but the destination can still reject that proxy IP during a browser challenge.

Ports

PORT

Default: 8191

API listener port. It defaults to 8191, the same port used by FlareSolverr and Byparr. The supplied Compose files use ${PORT:-8191} for the host side of the 8191 container mapping.

To run TRAWL alongside FlareSolverr (or any other service that already binds 8191 on the host), set PORT in your shell or .env to any free port before running docker compose up:

PORT=9191 docker compose up -d
# TRAWL reachable at http://localhost:9191, while port 8191 stays free for FlareSolverr.

Forward proxy

The optional general HTTP/HTTPS proxy has its own listener, CA, tier cap, and debug settings. See Proxy Configuration for all MITM_* variables and deployment examples.

---

The repository's .env.example is the canonical copyable environment template.

Upgrading from an earlier release?

The configuration namespaces changed without legacy aliases. Follow the complete configuration migration table before recreating the container.

Request deadlines and resource limits

maxTimeout is shared by HTTP fetching, waiting for a browser, navigation, challenge handling, CAPTCHA solving and requested captures. Expiry aborts HTTP/transcription, stops owned FFmpeg subprocesses and closes the request's page or temporary context. Cleanup is bounded separately (up to five seconds for a page/context); replacing an unhealthy browser may continue after the request has ended. An expired request does not start additional capture work.

BROWSER_MAX_CONTENT_PROCESSES is not a limit on all OS processes or threads: Firefox also runs network, extension and other helper processes, and isolates sites separately. BROWSER_HARDWARE_CONCURRENCY controls the CPU count reported to page scripts, not a CPU quota. A 1 GiB limit can still be exceeded by an unusually demanding page; use Docker resource limits and measure the target workload. Disabling ad blocking may reduce extension overhead while increasing page subresource traffic.

Named browser sessions

BROWSER_SESSION_MAX_ENTRIES (default 4) limits isolated contexts created through /sessions or /v1 session commands. BROWSER_SESSION_TTL_SECONDS (default 3600) expires idle sessions and frees their contexts. These settings are independent of the domain clearance cache and REDIS_SESSION_TTL_SECONDS.

Start with BROWSER_SESSION_MAX_ENTRIES=1 on a small container. Multiple contexts retain more memory, even after their request pages close. Live sessions postpone count-based recycling and idle retirement; memory pressure and crash recovery can still invalidate them. See Browser Sessions.
